Description:

This UNI - T UT181A is a 60000 counts 4 5/6 digits, handheld auto-range true RMS intelligent multimeter. The overall circuits are designed with LSI ADC as the core. The full-range overload protection circuit and unique appearance design make it to be a special electrical meter with superior performance.

Features:

- It can be used to measure the parameters such as AC and DC voltage, AC and DC current, resistance, conductance, diode, continuity, capacitance, temperature, frequency and pulse width, and it is provided with the functions of data hold, maximum / minimum / average measurement, comparison measurement, relative measurement, peak detection, trends capture and data record / readback as many as 2000 pieces

- Easy use and clear read, with large LCD display which is visible in low light, allows you to read information even in the dark - Trend capture: you can monitor for a long time, record the process of signal changes and the formation of trends for comparison

- Data filtering function: you can set the upper and lower data of any gear compared with the measured object, and there is error alarm if there have a gap

- IP65 waterproof, prevent meter from rain and dust

- Provides more information. The screen can display multiple data

- Dual temperature simultaneous measurements: intuitive and real-time temperature contrast, improve work efficiency

- Low-pass filtering: can be used for inverter and motor drive measurement

- Built-in 2200mAh Li-ion battery, long battery life

- Peak detection function records transients as fast as 250us

- USB data transfer, quick and stable

- Wider range of applications, more secure measurement, to ensure the safety of measure workers and instruments

Specifications:

Model: UT181A

Material: ABS

DC voltage: 60mV / 600mV / 6V / 60V / 600V / 1000V; accuracy: + / - (0.025pct + 5)

AC voltage: 60mV / 600mV / 6V / 60V / 600V / 1000V; accuracy: + / - (0.3pct + 30)

DC current: 600uA / 6000uA / 60mA / 600mA / 10A; accuracy: + / - (0.8pct + 10)

AC current: 600uA / 6000uA / 60mA / 600mA / 10A; accuracy: + / - (0.6pct + 20)

Resistance: 600 ohm / 6k ohm / 60k ohm / 600k ohm / 6m ohm / 60m ohm; accuracy: + / - (0.05pct + 2)

Conductance: 60 nS; accuracy: + / - (0.2pct + 10)

Capacitance: 6 nF / 60 nF / 600 nF / 6 uF / 60 uF / 600 uF / 6 mF / 60 mF; accuracy: + / - (0.2pct + 5)

Frequency: 10Hz - 60MHz; accuracy: + / - (0.01pct + 5)

Max display: 59999

Diode around: 3V

Frequency response: 100KHz

Lowpass: 1KHz (-3dB)

Data logging: 20000

Display: 3.5 inch, 67K color TFT LCD (320 x 240)

Temperature: -40 - 1000 Deg.C; accuracy: + / - (1pct + 30)

Dual temperature measurement: T1, T2, T1 - T2, T2 - T1

True RMS: yes

Auto range: yes

Analogue bar graph: 61

Continuity buzzer: yes

Data comparison: yes

Data hold: yes

Auto power off: yes

Low battery indication: yes

Package weight: 1.395 kg

Package Size(L x W x H): 23.50 x 6.00 x 29.00 cm / 9.25 x 2.36 x 11.42 inches

Package Includes:

1 x Multimeter, 1 x Power Adaptor, 1 x USB Cable, 2 x Test Lead, 2 x Point Contact Temperature Probe, 1 x Temperature Adaptor, 1 x Charging Connector, 1 x Bag, 2 x English and Chinese User Manual, 1 x CD

PT0303H Smart Calendar Clock with Temperature and Humidity Displays

Description:

This UNI - T UT181A is a 60000 counts 4 5/6 digits, handheld auto-range true RMS intelligent multimeter. The overall circuits are designed with LSI ADC as the core. The full-range overload protection circuit and unique appearance design make it to be a special electrical meter with superior performance.

Features:

- It can be used to measure the parameters such as AC and DC voltage, AC and DC current, resistance, conductance, diode, continuity, capacitance, temperature, frequency and pulse width, and it is provided with the functions of data hold, maximum / minimum / average measurement, comparison measurement, relative measurement, peak detection, trends capture and data record / readback as many as 2000 pieces

- Easy use and clear read, with large LCD display which is visible in low light, allows you to read information even in the dark - Trend capture: you can monitor for a long time, record the process of signal changes and the formation of trends for comparison

- Data filtering function: you can set the upper and lower data of any gear compared with the measured object, and there is error alarm if there have a gap

- IP65 waterproof, prevent meter from rain and dust

- Provides more information. The screen can display multiple data

- Dual temperature simultaneous measurements: intuitive and real-time temperature contrast, improve work efficiency

- Low-pass filtering: can be used for inverter and motor drive measurement

- Built-in 2200mAh Li-ion battery, long battery life

- Peak detection function records transients as fast as 250us

- USB data transfer, quick and stable

- Wider range of applications, more secure measurement, to ensure the safety of measure workers and instruments

Specifications:

Model: UT181A

Material: ABS

DC voltage: 60mV / 600mV / 6V / 60V / 600V / 1000V; accuracy: + / - (0.025pct + 5)

AC voltage: 60mV / 600mV / 6V / 60V / 600V / 1000V; accuracy: + / - (0.3pct + 30)

DC current: 600uA / 6000uA / 60mA / 600mA / 10A; accuracy: + / - (0.8pct + 10)

AC current: 600uA / 6000uA / 60mA / 600mA / 10A; accuracy: + / - (0.6pct + 20)

Resistance: 600 ohm / 6k ohm / 60k ohm / 600k ohm / 6m ohm / 60m ohm; accuracy: + / - (0.05pct + 2)

Conductance: 60 nS; accuracy: + / - (0.2pct + 10)

Capacitance: 6 nF / 60 nF / 600 nF / 6 uF / 60 uF / 600 uF / 6 mF / 60 mF; accuracy: + / - (0.2pct + 5)

Frequency: 10Hz - 60MHz; accuracy: + / - (0.01pct + 5)

Max display: 59999

Diode around: 3V

Frequency response: 100KHz

Lowpass: 1KHz (-3dB)

Data logging: 20000

Display: 3.5 inch, 67K color TFT LCD (320 x 240)

Temperature: -40 - 1000 Deg.C; accuracy: + / - (1pct + 30)

Dual temperature measurement: T1, T2, T1 - T2, T2 - T1

True RMS: yes

Auto range: yes

Analogue bar graph: 61

Continuity buzzer: yes

Data comparison: yes

Data hold: yes

Auto power off: yes

Low battery indication: yes

Package weight: 1.395 kg

Package Size(L x W x H): 23.50 x 6.00 x 29.00 cm / 9.25 x 2.36 x 11.42 inches

Package Includes:

1 x Multimeter, 1 x Power Adaptor, 1 x USB Cable, 2 x Test Lead, 2 x Point Contact Temperature Probe, 1 x Temperature Adaptor, 1 x Charging Connector, 1 x Bag, 2 x English and Chinese User Manual, 1 x CD
